100-6000kg/H Fish shrimp feed pellet machine Extruder

100-6000kg/H Fish shrimp feed pellet machine Extruder
100-6000kg/H Fish shrimp feed pellet machine Extruder
100-6000kg/H Fish shrimp feed pellet machine Extruder 100-6000kg/H Fish shrimp feed pellet machine Extruder 100-6000kg/H Fish shrimp feed pellet machine Extruder 100-6000kg/H Fish shrimp feed pellet machine Extruder

Large Image :  100-6000kg/H Fish shrimp feed pellet machine Extruder

Product Details:
Place of Origin: China
Brand Name: SBN
Certification: CE ISO BV SGS
Model Number: SLG65 SLG70 SLG85 SLG95 SLG120
Payment & Shipping Terms:
Minimum Order Quantity: 1 set
Price: 30000
Packaging Details: wooden case
Delivery Time: 30-60 days
Payment Terms: T/T, L/C
Supply Ability: 3 sets per month

100-6000kg/H Fish shrimp feed pellet machine Extruder

Description
Machine Name: 100-6000kg/h Fish Shrimp Feed Pellet Extruder Machine Machine Output: 100kg/h-6000kg/h
Automatic: Fully Automatic Finished Food: 1-20mm Floating,sinking Fish Feed,shrimp Feed
Machine Material: Stainless Steel 201,304,316
High Light:

6000kg/H Shrimp Feed Pellet Machine

,

100kg/H Shrimp Feed Pellet Machine

,

6000kg/H shrimp feed making machine

                                 100-6000kg/h Fish shrimp feed pellet extruder machine

1.Feed Machinery /Floating Feed Extruder Machine process flow:
Raw material preparation→Mixing raw material→Conveying→Extrusion→Conveying→Drying→Screening→Oil spraying→Flavoring→Packing


100-6000kg/H Fish shrimp feed pellet machine Extruder 0
2.Feed Machinery /Floating Feed Extruder Machine setting:

Mixer→Conveyor→Extruder→Wind conveyor/hoister→Multi-layer dryer→Sifter→Hoister→Oil sprayer→Single/double roller→Packing machine

In some cases,the production need to mill, and can adopt:Mixer→Conveyor→Extruder→Crusher→Packing machine

3.Feed Machinery /Floating Feed Extruder Machine specifications:

ModelInstalled powerReal powerOutputDimension
SLG6570kw40kw100-150kg/h22000*1200*2200mm
SLG7090kw50kw200-240kg/h25000*1500*2200mm
SLG85120kw100kw400-500kg/h30000*3500*4300mm
SLG95165kw115kw1000-2000kg/h30000*3500*4300mm


4.Machine detail:
1 Mixer:There are 3 machine model numbers to choose from base on the production capacity.
2 Conveyor:To convey raw materials to the extruder machine
3 Extruder machine: To choose DSE model extruders base on the production capacity requirement from 100kg per hour to 3ton per hour. The raw material include corn powder, cereal powder, soybean powder, shrimp powder and so on. Size of the pellet depends on the moulds. The pellet size our machine can produce are 0.5mm, 1mm, 2mm, 3mm, 4mm, 5mm,6mm.
4 Hoister: Convey the food to the dryer, the height of the hoister depends on the dryer.
5 Multilayer dryer:Electric dryer, controlled by control box, temperature range 0-200ºC.Inside is stainless steel double layer mesh net. Drying time is adjustable according to speed. We have dryers of 3 layer 5 meter, 5 layer 5 meter, 5 layer 7 meter, 5 layer 8 meter, 7 layer 8 meter, and 5 layer 11 meter steam dryer.
6 Sifter:To remove scrap
7 Flavoring line: To spray oil and phagostimulant, the equipment are: single roller, double roller, round roller, eight-angle roller. Varies depends on the different production line setting, to spray oil to the surface of the product and make it even.
8 Cooling conveyor: To lower the product temperature in order to pack it easily.
9 Sifter: To remove the wasted material and ensure quality, meanwhile to ensure the reuse of materials.
10 Packing machine: Manual and automatic packing machine.
100-6000kg/H Fish shrimp feed pellet machine Extruder 1


5.Our wide product range:
For now, our main products are Food Twin Screw extruder, Feed Twin Screw extruder, Fish food machine, Dog Food machine, Pet Cat Food machine, Doritos Tortilla chips machine, Nik naks Kurkure Cheetos machine, Modified starch machine, Corn flakes machine, Corn puffs Cheese ball machine, Frying pellets machine, Artificial rice Puffed rice machine; Core filling Pillow Tube Finger snack machine; Vertical Packaging machine, Flowpack packaging machine. Our Feed Extruder for Fish Dog Cat Main Market is Africa(like Nigeria, Uganda); Asia(Like Turkey, Uzbekistan, Iran, India, Indonesia, Thailand, Malaysia); Oceania(Australia); North America(Canada); Central America & South America(like Mexico, Venezuela, Costa Rica, Latvia, Brazil, Peru, Uruguay, Paraguay, Chile, Argentina)
6.Customer visiting & about me:
We sincerely welcome you and your team visit our factory, it will be highly appreciated if you can bring sample to us, we will let our technician test machine for you accordingly.
Any inquiry or Interests, Please feel free to contact me or whatsapp or leave me message

100-6000kg/H Fish shrimp feed pellet machine Extruder 2
7.FAQ
1. Q: Are you a trading company or a manufacturer?
A: We are the manufacturer, which has almost 10 years of experience in this industry.
2. Q: How can I get to your company?
A: That's great you can visit our factory, welcome! You can get a flight to Jinan Airport. Our factories are just about 30 minutes drive away from Jinan Airport.We are so glad to arrange our car pick you up!
3. Q: How long is your guarantee?
A: One year(Calculated from the equipment arrives the customer's side.).
After this period we will definitely support you when needed.
You will be welcome to contact us with any problem may happened.
4. Q: Will you send engineers to install the plant?
A: yes, but at an extra cost payable by the customer.
Or you can get local contractors to do the commissioning and we send one supervising engineer.
Packaging & Shipping
Packing: Simple packing stretch film (Based on the customers' need adopt the wooden case or wooden pellets, etc.)
Transportation: According to the contract, our company could in charge for the shipment or you prepaid. We will choose the most timely and safe way transportation.


8.Service
Our Services Our wooden packing for exporting level before delivery:
Our engineer would go to buyers place to installing the machinery to buyers.After the machinery arrived at buyers place .
1). At least 1 year from the date of completion of the commissioning.
2). Free consultation service before, during, and after sales;
3). Free project planning and design services;
4). Free debugging of equipment until everything is functional;
5). Free management of equipments long distance shipping;
6). Free training of equipment maintenance and operating personally;
7). Free new production techniques and formulas;
8). Provide 1 year complete warranty and life-time maintenance service;
100-6000kg/H Fish shrimp feed pellet machine Extruder 3
